Air duct "nozzle" broke off

Discussion in 'LR3' started by Olli Rita, Oct 10, 2018.

  1. Olli Rita

    Olli Rita Member

    Posts:
    15
    Likes Received:
    5
    Joined:
    Jan 9, 2017
    Location:
    Florida
    So while changing the alternator I had to remove the air duct, the piece after the filter box, and the vacuum nozzle on the side broke off. I thought it would be an easy fix, so when I went to pick up the alternator I asked the parts buy, and he told me it comes as ONE part.... I guess I could have used RTV or something else to temp fix it, but I live on a dirt road and the temps usually don't last that long.

    Designed the part in Fusion 360 and 3d printed it, with threads and a nut.... worked out pretty nicely.[​IMG]

    [​IMG]

    [​IMG]

    [​IMG]

  2. Houm_WA

    Houm_WA Full Access Member

    Posts:
    3,443
    Likes Received:
    74
    Joined:
    Jan 6, 2006
    ...purple though? :)

  3. Olli Rita

    Olli Rita Member

    Posts:
    15
    Likes Received:
    5
    Joined:
    Jan 9, 2017
    Location:
    Florida
    Leftovers from the kids fidget days.... it was supposed to be a prototype but came out perfect the first time, nobody will ever say it was a store bought ;)

  4. Houm_WA

    Houm_WA Full Access Member

    Posts:
    3,443
    Likes Received:
    74
    Joined:
    Jan 6, 2006
    Sorry...I live in the land of the University of Washington Huskies and it's a knee-jerk reaction to barf when I see purple!

  5. Olli Rita

    Olli Rita Member

    Posts:
    15
    Likes Received:
    5
    Joined:
    Jan 9, 2017
    Location:
    Florida
    Have no idea who Huskies are, so no problem for me.

  6. Houm_WA

    Houm_WA Full Access Member

    Posts:
    3,443
    Likes Received:
    74
    Joined:
    Jan 6, 2006
    You're lucky....

  7. Olli Rita

    Olli Rita Member

    Posts:
    15
    Likes Received:
    5
    Joined:
    Jan 9, 2017
    Location:
    Florida
    You should have seen the other left over color choices, hot pink, neon green and yellow.... you understand why I didn't bother changing the spool :)

    Houm_WA likes this.
  8. joey

    joey Custom Rover Accessories Staff Member

    Posts:
    9,792
    Likes Received:
    54
    Joined:
    Jun 28, 2004
    I love fusion 360... is this PLA? If so it may not hold up well under the heat of the engine. I would recommend ABS or Poly-carbonate

  9. Olli Rita

    Olli Rita Member

    Posts:
    15
    Likes Received:
    5
    Joined:
    Jan 9, 2017
    Location:
    Florida
    PETG should hold up fine, I was supposed to do final print out of Abs....
